M34
www.vishay.com
ENVIRONMENTAL CHARACTERISTICS
Vishay
ITEM
Hermeticity
Moisture resistance
Altitude
CONDITION
MIL-PRF-39006
MIL-PRF-39006
MIL-STD-202G, method 105 D
COMMENTS
There shall be no evidence of leakage after
testing to MIL-PRF-39006 specifications.
Tested in accordance to MIL-PRF-39006 for
30 cycles.
100 000 feet test
MECHANICAL CHARACTERISTICS
ITEM
Thermal shock
Shock
Vibration (high frequency)
Resistance to solder heat
Solderability
Terminals
Part markings
Weight (typical) in g
CONDITION
MIL-STD-202G, method 107 A
MIL-STD-202G, method 213 I
MIL-STD-202G, method 204 D
MIL-STD-202G, method 210 F
ANSI J-STD-002
MIL-STD-1276
MIL-STD-1285
3.5
COMMENTS
Per M39006 and DSCC93026, 30 cycles
Per M39006 and DSCC93026, 100 g
Per M39006 and DSCC93026, 20 g
Terminals at 260 °C for 10 s. The capacitor
must not be visibly damaged and the electrical
characteristics must not be affected.
The terminations must be solderable per the
MIL standard.
All terminals shall be permanently secured
internally and externally, as applicable. All
external joints shall be welded.
The part marking shall include Vishay name,
trademark, capacitance, voltage, date code
and lot symbol.
PAD DIMENSIONS in millimeters
A
C
B
C
CASE CODE
C
A (MIN.)
22.7
B (NOM.)
14.7
C (NOM.)
4.0
D (NOM.)
6.4
STANDARD PACKAGING QUANTITY
Revision: 28-Jul-11
SERIES
M34
CASE CODE
C
4
BULK/TUBE
10 pcs
Document Number: 40106
For technical questions, contact: tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
